55CA: Single Channel Rugged Charge Amplifier
Accelerometer charge conversion. Request Quote Download Spec Sheet Each 55CA Charge Amplifier provides one (1) channel of charge amplification, a buffered acceleration output signal, and an integrated (velocity) signal output. It also provides single-ended and differential outputs. About the 55CA: Single Channel Rugged Charge Amplifier Accelerometer Charge Conversion The 55CA Charge Amplifier conditions and amplifies charge-mode accelerometer signals. It is a rugged device designed to be used in engine test cells and other environments where charge-mode accelerometers are used to measure machinery vibration. Galvanic separation ensures that ground loops will [...]
41CA: Dual Channel Rugged Charge Amplifier
Convert accelerometer charge signals into voltage signals Request Quote Download Brochure The 41CA Two Channel Charge Amplifier is used to convert accelerometer charge signals into voltage signals. Converted signals are then easily used by the PBS-4100 family of vibration analyzers. Two channels of amplification are provided. Each channel has separate gain and switchable test signals. Input Signal Configuration: Differential or Single Ended Channel gain settings: 1, 4, 10 mV/pC Highpass filter options: 0, 10, 15, 20, 25 Hz Lowpass filter options: 10K, 5K, 2K, 500 Hz What Stands Out With [...]
CA1800: Rack-mount Multiple Channel Charge Amplifier
Precision test cell rack mounted accelerometer charge amplifier Request Quote Download Brochure This CA1800 provides up to eight (8) channels of precision charge amplification for accelerometers and other charge mode devices. Up to eight (8) channels of amplification Self contained compact 19 inch rack mountable chassis Independent gain settings for each channel All input connections on rear panel Buffered acceleration signals available on front panel Optional filtering available Complete operation guide available The Features and Advantages of Our CA1800: Rack-Mount Multiple Channel Charge Amplifier MTI's CA1800 is a rack-mount multiple-channel charge [...]
SEM/LM-based Tensile Systems
This product is no longer being offered by MTI Instruments. SEM/LM-based Tensile Systems In-situ material tensile stage solution for SEMs
PBS-4100R+ Test Cell Vibration and Balancing System
PBS-4100R+ Test Cell Vibration and Balancing System Request Quote Download Data Sheet The “one-shot” balancing solution for test cells. Test cell vibration analysis and jet engine trim balance instruments and accessories for commercial and military aviation gas turbine engines. Designed to quickly isolate engine problems and locate troubles. Rapid configuration and intuitive user interface make it straightforward and uncomplicated to use. In testing an engine, the operator will execute a vibration survey on the turbine engine. The survey is a slow cycling of engine speed from idle to maximum, then back down to idle [...]
Downloads
[download_page show_search=true posts_per_page=50 default_orderby=title show_tags=false]
Engine Vibration and Balancing Principles
What do you think when you’re flying home, cruising at 30,000 feet and the drinks have just been served? Our engineers think about the ripple in the glass. That ripple signals vibration and is an indication that the engine may be in need of a balance. The MTII’s PBS-4100+ Series Turbine Vibration Analyzer/Balancing System was developed to ensure that Turbine engines run as efficiently as possible. Excessive vibration is detrimental for a host of reasons: energy intended for useful output is instead expended on the vibration vibration manifests as acoustic energy (noise), again wasting otherwise useful energy excessive [...]
Handheld Signal Source Generator Principles
The MTI 1510A Portable Signal Generator is a sophisticated two channel battery powered microprocessor controlled direct digital synthesizer. It can generate sine, square, saw tooth and triangle continuous signals on both channels as well as single pulse and odd pulses on the B channel to simulate tachometer output pulses. The main reason for two channels is to be able to create a phase shift in the A to B output signals as may be encountered in a piece of rotating equipment such as a jet engine. The A channel also has the ability to simulate precise DC signals or [...]
Non-Contact Measurement
Non-Contact Measurement Capacitance Sensors Measurements 25μm to 12mm Min. Resolution 20nm View Products Fiber Optic Sensors Measurements 102μm to 7.6mm Min. Resolution 0.1μm View Products 1D Laser Systems Measurements 2mm to 400mm Min. Resolution 0.04μm View Products 2D/3D Laser Systems Measurements 6mm to 1m (Z) Min. Resolution 3μm View Products What is Non-Contact Displacement Sensing? Non-Contact displacement sensing can be accomplished by a variety of different types of sensors such as eddy current , capacitance, laser triangulation, confocal chromatic [...]
PBS-4100+ Portable Vibration and Balancing System
Portable balancing system for gas turbine jet engines and vibration analysis Request a Quote Download Brochure Portable vibration analysis and engine trim balance instruments and accessories for commercial and military aviation. Designed to swiftly pinpoint jet engine problems and eliminate avoidable engine removals. Rapid configuration and intuitive user interface make this balancing system straightforward and uncomplicated to use. Portable Balancing System Vibration analysis and jet engine trim balance instruments and accessories for commercial and military aviation. Designed to swiftly pinpoint engine problems and eliminate avoidable engine removals. Rapid configuration and [...]
